Part 0: Setup & Environment

Bobchestrate Advanced Workshop Setup

Duration: 15–20 minutes

Objective: Get your development environment ready for building advanced watsonx Orchestrate agents

Prerequisites Check

Before starting, ensure you have:

  • [ ] Python 3.11–3.13 installed
  • [ ] uv installed
  • [ ] IBM Bob IDE installed
  • [ ] watsonx Orchestrate SaaS access (your instructor will provide credentials)
  • [ ] A Groq API key (free — sign up at console.groq.com) — needed for Part 1
  • [ ] A News API key (free — sign up at newsapi.org) — needed for Part 1

Step 1: Verify Python Installation

Open a terminal and run:

python --version
# or
python3 --version

You need Python 3.11, 3.12, or 3.13. If Python is not installed:

# Using Homebrew (recommended)
brew install python@3.11

# Or download the installer from:
# https://www.python.org/downloads/

# Using winget
winget install Python.Python.3.11

# Or download the installer from:
# https://www.python.org/downloads/
# ⚠️ Check "Add Python to PATH" during installation

Step 2: Verify uv Installation

uv --version

If uv is not installed:

# Using Homebrew
brew install uv

# Or using the official installer
curl -LsSf https://astral.sh/uv/install.sh | sh

# Using winget
winget install astral-sh.uv

# Or using the official installer (PowerShell)
powershell -ExecutionPolicy ByPass -c "irm https://astral.sh/uv/install.ps1 | iex"

After installing, open a new terminal and run uv --version again to confirm.

Step 3: Download and Extract the Workshop Folder

The Bob config zip is your workspace folder — extracting it creates bobchestrate-advanced/ with the .bob/ configuration already in place. No need to create a folder manually.

  1. Download the zip: advanced/part0-setup/bobchestrate-advanced.zip
  2. Extract it — extract to your Desktop or a convenient location

Mac/Linux:

cd ~/Desktop
unzip ~/Downloads/bobchestrate-advanced.zip
# This creates: ~/Desktop/bobchestrate-advanced/

Windows (PowerShell):

cd $env:USERPROFILE\Desktop
Expand-Archive -Path "$env:USERPROFILE\Downloads\bobchestrate-advanced.zip" -DestinationPath .
# This creates: Desktop\bobchestrate-advanced\

After extracting, your bobchestrate-advanced/ folder already contains:

bobchestrate-advanced/
└── .bob/
    ├── mcp.json
    ├── custom_modes.yaml
    ├── rules/
    │   └── wxo-dev-rule-enhanced.md
    └── skills/
        └── wxo-langgraph/

Note: The .bob folder may be hidden in your file explorer (it starts with a dot). That's expected — Bob IDE will find it automatically.

What the bundle gives you:

Component What it does
WXO Agent Architect mode A Bob chat mode specialised for watsonx Orchestrate development — automatically consults live wxO docs before answering and uses the ADK MCP server to inspect your environment
wxo-dev-rule-enhanced A workspace rule that loads IBM watsonx Orchestrate best practices into every Bob response — correct naming conventions, tool patterns, agent YAML structure, connection setup, and more
watsonx-orchestrate-adk MCP server Gives Bob direct access to your wxO environment — list agents, tools, connections, import artifacts, and chat with agents without leaving the IDE
watsonx-orchestrate-adk-docs MCP server Gives Bob real-time access to the full IBM watsonx Orchestrate ADK documentation — Bob searches it automatically when it needs to verify platform specifics
wxo-langgraph skill Deep LangGraph-for-wxO knowledge: entry point contract, platform constraints, credential patterns, checkpointers, cross-session memory API, and a troubleshooting reference — auto-activates when you work on Part 1

These three layers work together and complement each other:

  • Mode — sets Bob's persona and behaviour for a session. The WXO Agent Architect mode tells Bob to think like a watsonx Orchestrate developer: consult the docs first, use the ADK MCP tools to inspect your live environment, and never add ibm-watsonx-orchestrate to requirements.txt. It's the "who Bob is" layer.
  • Custom rule — sets always-on constraints that apply to every response regardless of mode or topic. The wxo-dev-rule-enhanced rule enforces platform conventions (snake_case agent names, correct decorator imports, key_value connections, evaluation config format, etc.) so Bob never generates code that violates wxO best practices — even if you're chatting in a generic mode.
  • Skill — provides deep, topic-specific knowledge that Bob loads on demand. The wxo-langgraph skill is a compact reference covering every LangGraph-for-wxO pattern: the create_agent contract, platform constraints, credentials, checkpointers, memory API, and common errors. It activates automatically when the topic matches, so Bob answers LangGraph questions with platform-correct detail without you having to ask it to "remember the rules".

Together: the mode shapes how Bob approaches problems, the rule keeps every answer platform-safe, and the skill supplies the deep domain knowledge for the specific topic you're working on.

Step 4: Open IBM Bob IDE and Login

Download IBM Bob IDE: If you haven't installed it yet, download from bob.ibm.com/download Detailed install guide: bob.ibm.com/docs/ide/getting-started/install

Open Bob IDE and sign in with your IBM ID.

⚠️ You must be logged in to use Bob's AI capabilities throughout the workshop. If you encounter login issues, contact your instructor.

Step 5: Open Your Workshop Folder in Bob IDE

  1. In Bob IDE, click File → Open Folder
  2. Navigate to the extracted bobchestrate-advanced folder and click Open
  3. Click Yes, I trust the author when prompted

The workspace will open with the .bob/ configuration already in place.

Step 6: Create a Python Virtual Environment

  1. Open the Command Palette (Cmd+Shift+P / Ctrl+Shift+P)
  2. Type "Python: Create Environment" and select it
  3. Choose Venv
  4. Select Python 3.11, 3.12, or 3.13
  5. Wait for the environment to be created

You'll see a .venv folder appear in your workspace. Bob IDE automatically activates it in all new terminals (you'll see (.venv) in your terminal prompt).

Step 7: Install the watsonx Orchestrate ADK VS Code Extension

⚠️ If you already have the extension installed, please reload the Bob IDE window first! This ensures the extension properly detects your new virtual environment. Open the Command Palette (Cmd+Shift+P on Mac / Ctrl+Shift+P on Windows/Linux), type "Developer: Reload Window" and select it. The Bob IDE window reloads and the extension will restart. You can then proceed directly to Step 8. Do NOT use the extension to initialise the workspace!

Install the watsonx Orchestrate extension for IBM Bob IDE:

  1. Open the Extensions view in IBM Bob IDE (click the Extensions icon in the Activity Bar or press Cmd+Shift+X on Mac / Ctrl+Shift+X on Windows/Linux)
  2. Search for "watsonx Orchestrate"
  3. Click Install on the "watsonx Orchestrate ADK" extension
  4. Wait for the installation to complete
  5. Reload Bob IDE if prompted
  6. You should now see the extension icon appear in the Activity Bar — you do NOT need to open it. If you do, do NOT initialize the workspace using it, as this can cause issues with the setup procedure:

The IBM watsonx Orchestrate ADK VS Code extension provides:

  • Workspace Management — automatically creates and initializes folder structures for agent development
  • ADK Version Management — install and update the watsonx Orchestrate ADK directly from VS Code
  • Agent & Tool File Creation — assists with creating agent and tool files
  • Developer Edition Server Control — start/stop the watsonx Orchestrate Developer Edition server from the UI
  • Orchestrate AI Builder Assistant — interactive AI assistant for building and refining agents

⚠️ Do NOT open the extension itself — you just need it installed. Using the extension to initialise the workspace can cause issues!

Step 8: Install the watsonx Orchestrate SDK

  1. Look at the status bar at the bottom of Bob IDE — you should see a red ❌ indicating the ADK is not installed in your new virtual environment
  2. Click the red ❌
  3. Select the option to install the ADK
  4. Wait for installation to complete — the status bar will show a green ✅ with the version number

Step 9: Check that watsonx Orchestrate MCP servers and the WXO Agent Architect mode are available

As explained in Step 3, the zip file / extracted workspace directory already includes the needed MCP server and mode definitions. Now, let's test that they are registered correctly and Bob can use them.

  1. Verify the MCP servers are running:
  2. Open Bob's chat panel and select Agent or Ask mode
  3. Ask Bob: "What MCP servers are available?"
  4. Bob might ask you for permission, select "Approve for task"

  5. You should see both listed:

  6. watsonx-orchestrate-adk — tools for interacting with watsonx Orchestrate

  7. watsonx-orchestrate-adk-docs — watsonx Orchestrate documentation

Verify the WXO Agent Architect mode is available:

  1. Click the mode selector in Bob's chat panel
  2. You should see WXO Agent Architect in the list
  3. Select it — ask Bob: "What can you help me with in this mode?"
  4. You should see the main topics listed

Verify that the custom development rule is also active:

  1. Keep the WXO Agent Architect mode selected
  2. Ask Bob: "What custom rules you can use and have access to?"
  3. You should see the topics from the wxo-dev-rule-ehanced.md listed

Step 10: Connect to Your watsonx Orchestrate Environment

You need your watsonx Orchestrate API key and instance URL. Your instructor will provide these. If you're using your own instance, follow the optional section below.

OPTIONAL: Using your own watsonx Orchestrate SaaS instance

To get your API key:

  1. In the wxO console, click your profile icon (top-right)
  2. Select Settings → API details
  3. Click Generate API key, then Copy immediately
  4. Store it securely — it is shown only once

To get your instance URL: Copy the Service instance URL from the API details page.

Configure the ADK Environment

Option A: Using the ADK CLI

Open a terminal in Bob IDE (Terminal → New Terminal) and run:

# Add your environment
orchestrate env add -n my-advanced-wxo -u <your-api-url>

# Activate it
orchestrate env activate my-advanced-wxo -a <your-api-key>

You should see: [INFO] Environment 'my-advanced-wxo' is now active

⚠️ Authentication expires every two hours. When it expires, re-run orchestrate env activate with your API key. Keep your API key handy.

Option B: Using Bob

  1. Make sure WXO Agent Architect mode is selected in Bob's chat
  2. Ask Bob:
    Create a simple shell script to add and activate a new watsonx Orchestrate SaaS environment for the ADK. I have the environment URL and API key ready.
  3. Follow Bob's steps — it will create and run a script that sets up your environment - Bob will probably ask permissions to use the wxo-documentation MCP server, write the script and make it executable for you - grant access to Bob to all of these things ir order to proceed with the task
  4. When done, Bob will show also instructions how to use the scrip - follow them to add and activate your wxO SaaS environment to your ADK

Verify the connection in terminal:

orchestrate agents list

Open terminal to Bob IDE from the main menu: Terminal --> New Terminal. If configured correctly, the command lists any existing agents (or shows an empty list if none exist yet). Any output without an error means you're connected.

Step 11: Get Your Part 1 API Keys

Part 1 (LangGraph Agents) uses two external APIs. Get your free keys now so you have them ready.

Groq API Key

Used to run LLMs (Llama 3) for free via Groq's API.

  1. Go to console.groq.com
  2. Sign up for a free account
  3. Navigate to API Keys → Create API Key
  4. Copy and save your key — it starts with gsk_

News API Key

Used by the research_agent to fetch live news headlines.

  1. Go to newsapi.org
  2. Click Get API Key (free tier)
  3. Register and copy your key

You'll set these as environment variables later in Part 1:

export GROQ_API_KEY=gsk_your_key_here
export NEWS_API_KEY=your_news_key_here

Step 12: Understand the Advanced Workshop Structure

After completing setup, your workspace will look like this:

bobchestrate-advanced/
├── .bob/                               # Bob IDE configuration (from bundle)
│   ├── mcp.json                        # MCP server config
│   ├── custom_modes.yaml               # WXO Agent Architect mode
│   ├── rules/
│   │   └── wxo-dev-rule-enhanced.md    # wxO dev rule (loaded automatically)
│   └── skills/
│       └── wxo-langgraph/              # LangGraph skill (auto-activates in Part 1)
│           ├── SKILL.md
│           ├── constraints.md
│           ├── patterns/
│           └── ref/
└── .venv/                              # Python virtual environment

When you work through Part 1, your agent code will live in subfolders you create (e.g. agents/echo_agent/, agents/research_agent/). The lab guide tells you exactly where to put each file.

Using Bob in the Advanced Workshop

Bob is your AI pair programmer. With the bundle installed, Bob has:

  • WXO Agent Architect mode — specialised for building wxO agents, with access to live wxO docs
  • wxo-langgraph skill — deep knowledge of LangGraph-for-wxO patterns, constraints, credentials, memory, and common errors. Auto-activates when you ask LangGraph questions.
  • wxo-dev-rule-enhanced — platform best-practices loaded as a workspace rule

Effective Bob prompts for the advanced workshop:

✅ "Bob, help me build a LangGraph agent that calls the Groq API using a wxO connection"

✅ "Bob, my agent import is failing — here's the error: [paste error]"

✅ "Bob, what's the correct way to add a checkpointer to a LangGraph agent on wxO?"

✅ "Bob, show me the minimal agent.yaml structure for a LangGraph package import"

Less effective:

❌ "Bob, fix this" — too vague

❌ "Bob, make it work" — no context

Managing Bob sessions:

  • Continue the same session when working on the same agent or related tasks
  • Start a new task (click "Start New Task" in Bob's chat) when switching to a completely different topic

Troubleshooting

Issue: orchestrate: command not found

The SDK isn't installed or isn't in your PATH. Make sure your virtual environment is active and try reinstalling:

pip install ibm-watsonx-orchestrate

Issue: Authentication failed or 401 Unauthorized

Your wxO session has expired (sessions last 2 hours). Re-activate:

orchestrate env activate my-advanced-wxo -a <your-api-key>

Issue: Bob isn't responding or MCP servers show red

  1. Check the MCP server status via Command Palette → "MCP Servers"
  2. If servers show red, re-run "watsonx Orchestrate: Install WXO MCP Servers"
  3. If Bob is unresponsive, restart Bob IDE

Issue: .bob folder not found / WXO Agent Architect mode missing

The .bob folder needs to be at the root of your open workspace folder. Check:

ls -la bobchestrate-advanced/
# You should see: .bob/  .venv/

If missing, redo Step 3 (re-extract the zip into a fresh location).

Quick Reference

# Check ADK version
orchestrate --version

# Add wxO environment
orchestrate env add -n my-advanced-wxo -u <api-url>

# Activate wxO environment (re-run every 2 hours)
orchestrate env activate my-advanced-wxo -a <api-key>

# List active environments
orchestrate env list

# List agents
orchestrate agents list

# Import a LangGraph agent
orchestrate agents import \
  --package-root agents/my_agent \
  --config-file agents/my_agent/agent.yaml

# List tools
orchestrate tools list

# List connections
orchestrate connections list

# Get help
orchestrate --help

Next Steps

Once your setup is verified:

  • [ ] orchestrate agents list returns without error
  • [ ] Bob responds and shows WXO Agent Architect mode
  • [ ] MCP servers show green in the MCP Servers panel
  • [ ] You have your Groq and News API keys ready

You're ready for the first advanced lab!

Continue to → Part 1: Building Custom LangGraph Agents

Additional Resources
