Part 9: Multi-Agent Orchestration & Workflows¶

Duration: 30 minutes

Difficulty: Advanced

Note: This is a standalone advanced exercise that can be completed independently of earlier parts.

Overview¶

In this lesson, you'll learn how to build sophisticated multi-agent systems where specialized agents work together to solve complex tasks. You'll create agent hierarchies, implement routing logic, and orchestrate workflows across multiple agents.

This part introduces a complete travel planning system as an advanced example of multi-agent orchestration. Unlike the customer support system built in earlier parts, this is a self-contained exercise demonstrating advanced patterns.

What You'll Learn¶

When and why to use multiple agents
Creating specialized agents for specific domains
Building agent hierarchies (parent-child relationships)
Implementing intelligent routing between agents
Managing context and handoffs
Best practices for multi-agent systems

What You'll Build¶

Travel Planning System with multiple specialized agents:

Travel Concierge (parent) - Routes requests to specialists
Flight Specialist - Handles flight bookings
Hotel Specialist - Manages accommodation
Activity Planner - Suggests local activities
Budget Advisor - Provides cost analysis

Why Multi-Agent Systems?¶

Single Agent vs Multi-Agent¶

Single Agent Approach:

Customer Support Agent
├── 50+ tools
├── 10+ knowledge bases
├── Complex instructions (1000+ lines)
└── Handles everything

Problems:

❌ Overwhelming complexity
❌ Difficult to maintain
❌ Poor performance on specialized tasks
❌ Hard to test and debug

Multi-Agent Approach:

Orchestrator Agent
├── Order Specialist (5 tools, focused instructions)
├── Billing Specialist (3 tools, focused instructions)
├── Technical Support (8 tools, focused instructions)
└── Escalation Handler (2 tools, focused instructions)

Benefits:

✅ Clear separation of concerns
✅ Easier to maintain and update
✅ Better performance on specialized tasks
✅ Simpler testing and debugging
✅ Reusable specialists across systems

When to Use Multi-Agent Systems¶

Use Multi-Agent When...	Use Single Agent When...
Domain has distinct specializations	Task is simple and focused
Need expert-level performance	General knowledge is sufficient
System will grow over time	Requirements are stable
Multiple teams own different parts	Single team owns everything
Need to reuse specialists	Agent is purpose-built

Part 1: Understanding Agent Hierarchies¶

Agent Roles¶

1. Orchestrator (Parent) Agent

Routes requests to appropriate specialists
Manages overall conversation flow
Synthesizes responses from multiple agents
Handles general queries

2. Specialist (Child) Agents

Deep expertise in specific domain
Focused tools and knowledge
Clear, specific instructions
Return to orchestrator when done

Routing Strategies¶

1. Description-Based Routing The orchestrator uses agent descriptions to decide routing:

# Orchestrator sees these descriptions
collaborators:
  - flight_specialist  # "Handles flight searches, bookings, and changes"
  - hotel_specialist   # "Manages hotel reservations and accommodations"

2. Instruction-Based Routing Explicit routing logic in orchestrator instructions:

instructions: |
  When user asks about flights:
  - Route to flight_specialist

  When user asks about hotels:
  - Route to hotel_specialist

  When user needs both:
  - Route to flight_specialist first
  - Then route to hotel_specialist
  - Synthesize both responses

3. Tool-Based Routing (Supervisory Pattern) The orchestrator acts as a supervisor without domain-specific tools, delegating to specialists who have the actual tools:

# Orchestrator Agent (Supervisor)
# - Has NO flight/hotel/activity tools
# - Only has access to specialist agents as collaborators
# - Analyzes user request and delegates to appropriate specialist

# Flight Specialist Agent
# - HAS flight search and booking tools
# - Handles all flight-related operations

# Hotel Specialist Agent
# - HAS hotel search and booking tools
# - Handles all hotel-related operations

Why this works:

Orchestrator recognizes it lacks the tools needed for the task
It must delegate to a specialist agent that has those tools
This creates natural routing based on capability boundaries
Prevents the orchestrator from trying to handle domain-specific tasks directly

Part 2: Building Specialist Agents¶

Step 1: Create Flight Specialist¶

Download example flight-specialist-agent.yaml or ask Bob for it (look example prompt below the example yaml). HINT: you should ask Bob. It will create a better than the simple example 🤓 And it's only around 0.3 bobcoins 🪙

spec_version: v1
kind: native
name: flight_specialist
title: Flight Booking Specialist
description: Expert in flight searches, bookings, changes, and cancellations. Handles all flight-related queries including availability, pricing, and itinerary modifications.

instructions: |
  You are a flight booking specialist with deep expertise in air travel.

  Your capabilities:
  - Search for flights based on dates, destinations, preferences
  - Provide detailed flight information (times, prices, airlines)
  - Handle booking requests
  - Process flight changes and cancellations
  - Explain baggage policies and fees

  Guidelines:
  - Always ask for essential details: origin, destination, dates, passengers
  - Present options clearly with prices and durations
  - Highlight best value and most convenient options
  - Explain any restrictions or fees upfront
  - Confirm all details before booking

  When you've completed the user's flight-related request:
  - Summarize what was accomplished
  - Ask if they need anything else flight-related
  - If they need other travel services (hotels, activities), let them know
    you'll hand back to the travel concierge

  Response format:
  - Be concise but complete
  - Use bullet points for options
  - Include all relevant details (times, prices, airlines)
  - End with clear next steps

tools:
  - search_flights
  - book_flight
  - modify_flight
  - cancel_flight

llm: groq/openai/gpt-oss-120b

💡 Ask Bob:

Bob, create a flight_specialist_agent.yaml file with focused instructions
for handling flight bookings and searches.

When Bob is finished, you will have a new agent file stored to your agents directory. Have a look what Bob created for you. Quite professional, isn't it? With real guidelines and tool placeholder. We create the tools a bit later.

Step 2: Create Hotel Specialist¶

Download example hotel-specialist-agent.yaml or ask Bob for it. At this point, you should have some idea how to prompt this agent 😉 You can try several times until you are satisfied with the result.

spec_version: v1
kind: native
name: hotel_specialist
title: Hotel Booking Specialist
description: Expert in hotel accommodations, reservations, and lodging options. Handles hotel searches, bookings, modifications, and provides recommendations based on preferences and budget.

instructions: |
  You are a hotel booking specialist with extensive knowledge of accommodations.

  Your capabilities:
  - Search hotels by location, dates, and preferences
  - Provide detailed hotel information (amenities, ratings, prices)
  - Handle reservation requests
  - Process booking modifications and cancellations
  - Recommend hotels based on budget and needs

  Guidelines:
  - Ask for: location, check-in/out dates, guests, budget, preferences
  - Present 3-5 options with key details
  - Highlight amenities that match user preferences
  - Explain cancellation policies clearly
  - Confirm all details before booking

  When you've completed the user's hotel-related request:
  - Summarize the booking or recommendations
  - Ask if they need anything else hotel-related
  - If they need other travel services, indicate you'll return to
    the travel concierge

  Response format:
  - Clear hotel names and locations
  - Price per night and total cost
  - Key amenities (WiFi, breakfast, parking, etc.)
  - Guest ratings if available
  - Cancellation policy summary

tools:
  - search_hotels
  - book_hotel
  - modify_hotel_booking
  - cancel_hotel_booking

llm: groq/openai/gpt-oss-120b

Step 3: Create Activity Planner¶

Download example activity-planner-agent.yaml or ask Bob for it.

spec_version: v1
kind: native
name: activity_planner
title: Local Activity Specialist
description: Expert in local attractions, activities, tours, and experiences. Provides personalized recommendations for things to do based on interests, location, and travel dates.

instructions: |
  You are a local activity and experience specialist.

  Your capabilities:
  - Suggest activities based on location and interests
  - Provide details on tours, attractions, and experiences
  - Recommend restaurants and local cuisine
  - Suggest itineraries for different trip lengths
  - Provide insider tips and local knowledge

  Guidelines:
  - Ask about: destination, travel dates, interests, group size
  - Tailor suggestions to user preferences (adventure, culture, food, etc.)
  - Include practical details (duration, cost, booking requirements)
  - Suggest a mix of popular and off-the-beaten-path options
  - Consider timing and logistics

  When you've provided activity recommendations:
  - Summarize the suggested itinerary
  - Offer to provide more details on specific activities
  - If they need other travel services, indicate you'll return to
    the travel concierge

  Response format:
  - Activity name and brief description
  - Duration and best time to visit
  - Approximate cost
  - Why it's recommended for them
  - Booking/reservation requirements

tools:
  - search_activities
  - get_activity_details
  - search_restaurants
  - create_itinerary

llm: groq/openai/gpt-oss-120b

Step 4: Create Budget Advisor¶

Download example budget-advisor-agent.yaml or ask Bob for it. HINT: ever considered to ask Bob for a promt to create a certain type of an agent? Just thinking aloud here 😉

spec_version: v1
kind: native
name: budget_advisor
title: Travel Budget Specialist
description: Expert in travel cost analysis, budget planning, and money-saving strategies. Helps travelers understand costs, find deals, and optimize their travel budget.

instructions: |
  You are a travel budget and cost analysis specialist.

  Your capabilities:
  - Analyze total trip costs (flights, hotels, activities, meals)
  - Suggest budget-friendly alternatives
  - Identify money-saving opportunities
  - Compare costs across different options
  - Provide budget breakdowns and forecasts

  Guidelines:
  - Ask about: total budget, trip duration, priorities
  - Break down costs by category
  - Highlight where most money is spent
  - Suggest specific ways to save money
  - Be realistic about costs

  When you've completed the budget analysis:
  - Provide clear cost breakdown
  - Highlight savings opportunities
  - Recommend budget allocation
  - If they want to book based on your analysis, indicate you'll
    return to the travel concierge

  Response format:
  - Total estimated cost
  - Cost breakdown by category
  - Budget vs actual comparison
  - Money-saving recommendations
  - Alternative options if over budget

tools:
  - calculate_trip_cost
  - compare_options
  - find_deals
  - budget_optimizer

llm: groq/openai/gpt-oss-120b

Part 3: Creating the Orchestrator Agent¶

Step 1: Design Orchestrator Instructions¶

The orchestrator needs clear routing logic:

Download example travel-concierge-agent.yaml or ask Bob for it (look example prompt below the example yaml).

spec_version: v1
kind: native
name: travel_concierge
title: Travel Concierge
description: Your personal travel planning assistant that coordinates with specialists to help plan your perfect trip.

instructions: |
  You are a friendly travel concierge who helps users plan their trips by
  coordinating with specialized travel agents.

  Your role:
  - Understand the user's travel needs and preferences
  - Route requests to appropriate specialists
  - Synthesize information from multiple specialists
  - Provide a cohesive travel planning experience

  Available specialists:
  - flight_specialist: For all flight-related queries (searches, bookings, changes)
  - hotel_specialist: For accommodation needs (hotels, reservations)
  - activity_planner: For things to do, attractions, restaurants
  - budget_advisor: For cost analysis and budget planning

  Routing guidelines:

  1. Flight queries → flight_specialist
     Examples: "Find me flights to Paris", "Change my flight booking"

  2. Hotel queries → hotel_specialist
     Examples: "Find hotels in Tokyo", "Book a hotel near the airport"

  3. Activity queries → activity_planner
     Examples: "What should I do in Rome?", "Recommend restaurants"

  4. Budget queries → budget_advisor
     Examples: "How much will this trip cost?", "Help me save money"

  5. Complex queries → Multiple specialists in sequence
     Example: "Plan a week in London"
     - Route to flight_specialist first
     - Then hotel_specialist
     - Then activity_planner
     - Finally budget_advisor

  Workflow for complex requests:
  1. Break down the request into components
  2. Route to specialists in logical order
  3. Synthesize responses into cohesive plan
  4. Present complete solution to user

  General queries you handle directly:
  - Greetings and general questions
  - Travel tips and advice
  - Clarifying user needs
  - Summarizing plans

  Response style:
  - Friendly and helpful
  - Clear about which specialist is helping
  - Synthesize specialist responses naturally
  - Proactive in suggesting next steps

collaborators:
  - flight_specialist
  - hotel_specialist
  - activity_planner
  - budget_advisor

llm: groq/openai/gpt-oss-120b

💡 Ask Bob:

Bob, create a travel_concierge_agent.yaml that orchestrates between
the four specialist agents with clear routing logic. The collaborators are flight_specialist, hotel_specialist, activity_planner, and budget_advisor. The agent should handle complex multi-aspect travel requests by routing to the appropriate specialist and synthesizing responses.

Part 4: Implementing Mock Tools¶

For this workshop, we'll create mock tools that simulate the specialist capabilities. This allows us to focus on the orchestration logic without needing to integrate with real APIs yet. This approach is ideal for quick prototyping, demos and testing.

Create Flight Tools¶

Create flight_tools.py:

from ibm_watsonx_orchestrate.agent_builder.tools import tool

@tool
def search_flights(
    origin: str,
    destination: str,
    departure_date: str,
    return_date: str = None,
    passengers: int = 1
) -> dict:
    """
    Search for available flights.

    Args:
        origin: Departure city or airport code
        destination: Arrival city or airport code
        departure_date: Departure date (YYYY-MM-DD)
        return_date: Return date for round trip (YYYY-MM-DD)
        passengers: Number of passengers

    Returns:
        Dictionary with flight options
    """
    # Mock flight data
    flights = [
        {
            "flight_number": "AA123",
            "airline": "American Airlines",
            "departure": f"{origin} 08:00",
            "arrival": f"{destination} 14:30",
            "duration": "6h 30m",
            "price": 450.00,
            "stops": 0,
            "class": "Economy"
        },
        {
            "flight_number": "UA456",
            "airline": "United Airlines",
            "departure": f"{origin} 10:30",
            "arrival": f"{destination} 17:15",
            "duration": "6h 45m",
            "price": 425.00,
            "stops": 0,
            "class": "Economy"
        },
        {
            "flight_number": "DL789",
            "airline": "Delta",
            "departure": f"{origin} 14:00",
            "arrival": f"{destination} 22:00",
            "duration": "8h 00m",
            "price": 380.00,
            "stops": 1,
            "class": "Economy"
        }
    ]

    result = {
        "origin": origin,
        "destination": destination,
        "departure_date": departure_date,
        "return_date": return_date,
        "passengers": passengers,
        "flights": flights,
        "count": len(flights)
    }

    if return_date:
        result["trip_type"] = "round-trip"
        result["total_price_range"] = f"${flights[-1]['price'] * 2} - ${flights[0]['price'] * 2}"
    else:
        result["trip_type"] = "one-way"
        result["total_price_range"] = f"${flights[-1]['price']} - ${flights[0]['price']}"

    return result


@tool
def book_flight(
    flight_number: str,
    passenger_name: str,
    passenger_email: str
) -> dict:
    """
    Book a flight.

    Args:
        flight_number: Flight number to book
        passenger_name: Passenger full name
        passenger_email: Passenger email

    Returns:
        Booking confirmation
    """
    import random
    confirmation = f"CONF{random.randint(100000, 999999)}"

    return {
        "status": "confirmed",
        "confirmation_number": confirmation,
        "flight_number": flight_number,
        "passenger_name": passenger_name,
        "email": passenger_email,
        "booking_date": "2024-01-15",
        "message": f"Flight {flight_number} booked successfully! Confirmation: {confirmation}",
        "next_steps": [
            "Check-in opens 24 hours before departure",
            "Confirmation email sent to " + passenger_email,
            "Download boarding pass via airline app"
        ]
    }


@tool
def modify_flight(
    confirmation_number: str,
    new_date: str = None,
    new_flight: str = None
) -> dict:
    """
    Modify an existing flight booking.

    Args:
        confirmation_number: Booking confirmation number
        new_date: New departure date (optional)
        new_flight: New flight number (optional)

    Returns:
        Modification confirmation
    """
    changes = []
    if new_date:
        changes.append(f"Date changed to {new_date}")
    if new_flight:
        changes.append(f"Flight changed to {new_flight}")

    return {
        "status": "modified",
        "confirmation_number": confirmation_number,
        "changes": changes,
        "change_fee": 75.00,
        "fare_difference": 25.00,
        "total_cost": 100.00,
        "message": "Flight modified successfully. Total cost: $100.00 (change fee + fare difference)"
    }


@tool
def cancel_flight(confirmation_number: str) -> dict:
    """
    Cancel a flight booking.

    Args:
        confirmation_number: Booking confirmation number

    Returns:
        Cancellation confirmation
    """
    return {
        "status": "cancelled",
        "confirmation_number": confirmation_number,
        "cancellation_fee": 100.00,
        "refund_amount": 350.00,
        "refund_method": "original payment method",
        "processing_time": "5-7 business days",
        "message": "Flight cancelled. Refund of $350.00 will be processed within 5-7 business days."
    }

💡 Ask Bob:

Bob, create flight_tools.py with mock implementations of search_flights,
book_flight, modify_flight, and cancel_flight tools.

Create Hotel Tools¶

Create hotel_tools.py:

from ibm_watsonx_orchestrate.agent_builder.tools import tool

@tool
def search_hotels(
    location: str,
    check_in: str,
    check_out: str,
    guests: int = 2,
    max_price: float = None
) -> dict:
    """
    Search for available hotels.

    Args:
        location: City or area
        check_in: Check-in date (YYYY-MM-DD)
        check_out: Check-out date (YYYY-MM-DD)
        guests: Number of guests
        max_price: Maximum price per night

    Returns:
        Dictionary with hotel options
    """
    hotels = [
        {
            "name": "Grand Plaza Hotel",
            "location": location,
            "rating": 4.5,
            "price_per_night": 180.00,
            "amenities": ["WiFi", "Breakfast", "Pool", "Gym", "Parking"],
            "cancellation": "Free cancellation until 24h before",
            "distance_to_center": "0.5 miles"
        },
        {
            "name": "City Center Inn",
            "location": location,
            "rating": 4.0,
            "price_per_night": 120.00,
            "amenities": ["WiFi", "Breakfast", "Business Center"],
            "cancellation": "Free cancellation until 48h before",
            "distance_to_center": "0.2 miles"
        },
        {
            "name": "Budget Stay",
            "location": location,
            "rating": 3.5,
            "price_per_night": 80.00,
            "amenities": ["WiFi", "24h Reception"],
            "cancellation": "Non-refundable",
            "distance_to_center": "1.5 miles"
        },
        {
            "name": "Luxury Suites",
            "location": location,
            "rating": 5.0,
            "price_per_night": 350.00,
            "amenities": ["WiFi", "Breakfast", "Pool", "Spa", "Gym", "Restaurant", "Parking"],
            "cancellation": "Free cancellation until 72h before",
            "distance_to_center": "0.3 miles"
        }
    ]

    # Filter by max price if specified
    if max_price:
        hotels = [h for h in hotels if h["price_per_night"] <= max_price]

    # Calculate total cost
    from datetime import datetime
    check_in_date = datetime.strptime(check_in, "%Y-%m-%d")
    check_out_date = datetime.strptime(check_out, "%Y-%m-%d")
    nights = (check_out_date - check_in_date).days

    for hotel in hotels:
        hotel["total_cost"] = hotel["price_per_night"] * nights
        hotel["nights"] = nights

    return {
        "location": location,
        "check_in": check_in,
        "check_out": check_out,
        "guests": guests,
        "nights": nights,
        "hotels": hotels,
        "count": len(hotels)
    }


@tool
def book_hotel(
    hotel_name: str,
    guest_name: str,
    guest_email: str,
    check_in: str,
    check_out: str,
    room_type: str = "Standard"
) -> dict:
    """
    Book a hotel room.

    Args:
        hotel_name: Name of the hotel
        guest_name: Guest full name
        guest_email: Guest email
        check_in: Check-in date
        check_out: Check-out date
        room_type: Type of room (Standard, Deluxe, Suite)

    Returns:
        Booking confirmation
    """
    import random
    confirmation = f"HTL{random.randint(100000, 999999)}"

    return {
        "status": "confirmed",
        "confirmation_number": confirmation,
        "hotel_name": hotel_name,
        "guest_name": guest_name,
        "check_in": check_in,
        "check_out": check_out,
        "room_type": room_type,
        "email": guest_email,
        "message": f"Hotel booked successfully! Confirmation: {confirmation}",
        "check_in_time": "3:00 PM",
        "check_out_time": "11:00 AM",
        "next_steps": [
            "Confirmation email sent to " + guest_email,
            "Check-in starts at 3:00 PM",
            "Early check-in available upon request"
        ]
    }


@tool
def modify_hotel_booking(
    confirmation_number: str,
    new_check_in: str = None,
    new_check_out: str = None,
    new_room_type: str = None
) -> dict:
    """
    Modify hotel booking dates or room type.

    Args:
        confirmation_number: Booking confirmation number
        new_check_in: New check-in date (optional)
        new_check_out: New check-out date (optional)
        new_room_type: New room type (optional)

    Returns:
        Modification confirmation
    """
    changes = []
    if new_check_in:
        changes.append(f"Check-in changed to {new_check_in}")
    if new_check_out:
        changes.append(f"Check-out changed to {new_check_out}")
    if new_room_type:
        changes.append(f"Room type changed to {new_room_type}")

    return {
        "status": "modified",
        "confirmation_number": confirmation_number,
        "changes": changes,
        "modification_fee": 0.00,
        "message": "Hotel booking modified successfully. No modification fee."
    }


@tool
def cancel_hotel_booking(confirmation_number: str) -> dict:
    """
    Cancel hotel booking.

    Args:
        confirmation_number: Booking confirmation number

    Returns:
        Cancellation confirmation
    """
    return {
        "status": "cancelled",
        "confirmation_number": confirmation_number,
        "refund_amount": 240.00,
        "cancellation_fee": 0.00,
        "refund_method": "original payment method",
        "processing_time": "3-5 business days",
        "message": "Hotel booking cancelled. Full refund of $240.00 will be processed within 3-5 business days."
    }

💡 Ask Bob:

Bob, create hotel_tools.py with mock implementations of search_hotels,
book_hotel, modify_hotel_booking, and cancel_hotel_booking tools.

Create Activity Tools¶

Create activity_tools.py with tools for the activity planner:

💡 Ask Bob:

Bob, create activity_tools.py with mock implementations of search_activities, get_activity_details, search_restaurants, and create_itinerary tools.

The file should include:

search_activities: Search for activities based on location and interests
get_activity_details: Get detailed information about specific activities
search_restaurants: Find restaurants by cuisine and price range
create_itinerary: Generate day-by-day itineraries

Create Budget Tools¶

Create budget_tools.py with tools for the budget advisor:

💡 Ask Bob:

Bob, create budget_tools.py with mock implementations of calculate_trip_cost,
compare_options, find_deals, and budget_optimizer tools.

The file should include:

calculate_trip_cost: Calculate total trip costs with detailed breakdown
compare_options: Compare two travel options and provide recommendations
find_deals: Find current deals and discounts
budget_optimizer: Optimize budget allocation across categories

Part 4.5: Naming Convention for Shared Environment¶

⚠️ IMPORTANT: Workshop Naming Requirements - YOU CAN IGNORE IF YOU ARE NOT USING THE SHARED WXO ENVIRONMENT

Since all workshop participants are using a shared watsonx Orchestrate environment, you must add your initials as a postfix to all tool and agent names to avoid conflicts.

Naming Pattern¶

Use this pattern for all your tools and agents:

Tools: tool_name_XX (where XX are your initials)
Agent YAML filenames: agent-name-XX.yaml (dashes allowed in filename)
Agent name field: agent_name_XX (must use underscores, not dashes)

Example¶

If your name is Jane Smith (initials: JS), rename your tools and agents as follows:

Tools:

# In flight_tools.py
@tool
def search_flights_JS(...):  # Added _JS postfix
    """Search for available flights."""
    ...

@tool
def book_flight_JS(...):  # Added _JS postfix
    """Book a flight."""
    ...

Agent Files:

# Filename: flight-specialist-agent-JS.yaml (dashes OK in filename)
name: flight_specialist_JS  # IMPORTANT: Use underscores in name field, not dashes!
description: Specialist agent for flight bookings
instructions: |
  You are a flight booking specialist...
tools:
  - search_flights_JS      # Reference tools with _JS postfix
  - book_flight_JS
  - modify_flight_JS
  - cancel_flight_JS

⚠️ Critical Naming Rule:

YAML filename can use dashes: flight-specialist-agent-JS.yaml
Agent name field must use underscores: name: flight_specialist_JS
This is a watsonx Orchestrate requirement for proper agent registration

Complete Naming Checklist¶

Before importing, ensure you've renamed:

✅ Tool Files:

[ ] All @tool function names in flight_tools.py
[ ] All @tool function names in hotel_tools.py
[ ] All @tool function names in activity_tools.py
[ ] All @tool function names in budget_tools.py

✅ Agent Files:

[ ] Agent name field in flight-specialist-agent.yaml
[ ] Tool references in tools section
[ ] Agent name field in hotel-specialist-agent.yaml
[ ] Tool references in tools section
[ ] Agent name field in activity-planner-agent.yaml
[ ] Tool references in tools section
[ ] Agent name field in budget-advisor-agent.yaml
[ ] Tool references in tools section
[ ] Agent name field in travel-concierge-agent.yaml
[ ] Collaborator agent names in collaborators section

💡 Ask Bob:

Bob, add a postfix "_<your_initials>" to all tool function names in flight_tools.py, hotel_tools.py, activity_tools.py, and budget_tools.py. Then update all agent YAML files to use the renamed tools (activity planner to use activity tools, flifgt specialist to use flight tools, etc.) and add "_<your_initials>" postfix to agent name fields within their yaml-files.

NOTE: Needless to say, but update your initials to their placeholders in the prompt before sending it to Bob 😉

Why This Matters¶

Without unique names:

❌ Your tools will overwrite other participants' tools
❌ Your agents will conflict with others' agents
❌ Testing will produce unpredictable results
❌ You may accidentally use someone else's implementation

With unique names:

✅ Your tools and agents are isolated
✅ You can test independently
✅ No conflicts with other participants
✅ Clear ownership of your implementations

Part 5: Testing Multi-Agent Workflows¶

Import All Agents and Tools¶

# Import all tools
orchestrate tools import -k python -f tools/flight_tools.py
orchestrate tools import -k python -f tools/hotel_tools.py
orchestrate tools import -k python -f tools/activity_tools.py
orchestrate tools import -k python -f tools/budget_tools.py

# Import specialist agents
orchestrate agents import -f agents/flight-specialist-agent.yaml
orchestrate agents import -f agents/hotel-specialist-agent.yaml
orchestrate agents import -f agents/activity-planner-agent.yaml
orchestrate agents import -f agents/budget-advisor-agent.yaml

# Import orchestrator (must be last, after collaborators exist)
orchestrate agents import -f travel-concierge-agent.yaml

💡 Ask Bob:

Bob, create a shell script that imports all agents (flight specialist, hotel specialist, activty planner, budget advisor and finally tra) and their tools in the correct order. Make sure each agent is imported after its collaborators.

NOTE: Check the tools and agents importing syntax that Bob uses in the script that it generates. Even the information regrading the correct syntax is available in the custom development rule that we're using, sometimes Bob might fail to consult it before creating stuff.

Test Simple Routing¶

Test 1: Single Specialist

orchestrate chat ask --agent-name travel_concierge_agent_<your_initials> \
  "Find me flights from New York to London for next week"

Expected flow:

Concierge receives request
Routes to flight_specialist
Flight specialist searches flights
Returns results to user

Test 2: Multiple Specialists

orchestrate chat ask --agent-name travel_concierge_agent_<your_initials> \
  "Plan a 5-day trip to Paris including flights and hotels"

Expected flow:

Concierge receives request
Routes to flight_specialist for flights
Routes to hotel_specialist for hotels
Synthesizes complete plan
Returns to user

Test Complex Workflows¶

Test 3: Full Trip Planning

orchestrate chat ask --agent-name travel_concierge_agent_<your_initials> \
  "I want to visit Tokyo for a week. I have a budget of $3000. Help me plan everything including flights, hotel, and activities."

Expected flow:

Concierge breaks down request
Routes to flight_specialist
Routes to hotel_specialist
Routes to activity_planner
Routes to budget_advisor
Synthesizes complete itinerary
Returns comprehensive plan

Part 6: Best Practices¶

1. Agent Design¶

Keep Specialists Focused:

# ✅ Good - Focused specialist
name: flight_specialist
tools:
  - search_flights
  - book_flight
  - modify_flight
  - cancel_flight

# ❌ Bad - Too broad
name: travel-specialist
tools:
  - search_flights
  - search_hotels
  - search_activities
  - book_everything

Clear Descriptions:

# ✅ Good - Clear, specific description with collaborators
description: Expert in flight searches, bookings, changes, and cancellations.
  Handles all flight-related queries including availability, pricing, and
  itinerary modifications. Works with hotel_specialist and activity_planner
  for complete travel planning.

# ❌ Bad - Vague description
description: Helps with travel stuff

NOTE: Include mentions of collaborator agents in descriptions to help the orchestrator understand agent relationships and routing options.

2. Routing Logic¶

Explicit Routing Instructions:

instructions: |
  # ✅ Good - Clear routing rules
  When user asks about flights:
  - Route to flight_specialist
  - Wait for response
  - Present to user

  When user asks about hotels:
  - Route to hotel_specialist
  - Wait for response
  - Present to user

Handle Edge Cases:

instructions: |
  If user request is ambiguous:
  - Ask clarifying questions first
  - Then route to appropriate specialist

  If specialist cannot help:
  - Acknowledge limitation
  - Suggest alternative
  - Route to different specialist if appropriate

3. Context Management¶

Pass Relevant Context:

instructions: |
  When routing to specialist:
  - Include all relevant details from conversation
  - Mention previous specialist interactions if relevant
  - Provide user preferences and constraints

Synthesize Responses:

instructions: |
  After receiving specialist response:
  - Summarize key points
  - Connect to user's original request
  - Suggest logical next steps
  - Maintain conversation flow

4. Error Handling¶

Graceful Failures:

instructions: |
  If specialist returns error:
  - Explain issue to user clearly
  - Suggest alternatives
  - Offer to try different approach
  - Don't expose technical details

Timeout Handling:

instructions: |
  If specialist doesn't respond within expected time:
  - Acknowledge the delay to user
  - Explain what might be happening
  - Offer to try again or use alternative approach
  - Log timeout for debugging

  Example: "The flight specialist is taking longer than expected.
  This might be due to high search volume. Would you like me to
  try a simpler search or wait a bit longer?"

Input Validation:

instructions: |
  Before routing to specialist:
  - Validate user input completeness
  - Check for required parameters
  - Verify data format (dates, numbers, etc.)
  - Ask for missing information before routing

  Example: If user asks "book a flight" without destination,
  ask for required details before routing to flight_specialist.

Logging and Debugging:

instructions: |
  For debugging multi-agent workflows:
  - Log routing decisions and reasons
  - Track which specialist handled each request
  - Record context passed between agents
  - Note any errors or fallbacks used

  This helps identify issues in routing logic and specialist performance.

5. Optimizing Agent Performance¶

Agent Architecture:

# ✅ Good - Flat hierarchy with focused specialists
User → Orchestrator → Specialist → User

# ❌ Bad - Unnecessary intermediate layers
User → Orchestrator → Coordinator → Specialist → Coordinator → Orchestrator → User

# Keep your agent hierarchy simple. The LLM handles routing based on descriptions,
# so additional coordinator layers just add latency without improving routing.

Clear Agent Descriptions:

# The LLM uses descriptions to route requests
# Make them specific and action-oriented

# ✅ Good - Clear scope and capabilities
description: |
  Expert in flight searches, bookings, changes, and cancellations.
  Handles all flight-related queries including availability, pricing,
  and itinerary modifications. Works with hotel_specialist and
  activity_planner for complete travel planning.

# ❌ Bad - Vague or overlapping scope
description: Helps with travel arrangements

Explicit Routing Instructions:

instructions: |
  # Guide the LLM on when to route to specialists

  When user asks about flights:
  - Call the flight_specialist agent immediately
  - Do NOT ask for additional parameters before routing
  - Pass all available context from the conversation

  When user asks about hotels:
  - Call the hotel_specialist agent immediately
  - Include destination and dates if mentioned

  # Use explicit action verbs: "Call", "Execute", "Use"
  # Avoid implicit language: "delegate", "route", "consider"

Tool Design for Specialists:

# Keep specialist tools focused and simple
# LLMs perform best with ≤10 tools per agent

# ✅ Good - Focused tool set
flight_specialist:
  tools:
    - search_flights
    - book_flight
    - modify_booking
    - cancel_booking

# ❌ Bad - Too many tools
travel_agent:
  tools:
    - search_flights
    - search_hotels
    - search_activities
    - search_restaurants
    - book_flight
    - book_hotel
    # ... 20+ more tools

Reasoning Efficiency (for GPT-OSS-120B):

instructions: |
  # Limit reasoning depth to improve response time

  Reasoning and brevity controls:
  - Use concise reasoning with at most 3 reasoning steps
  - Do not re-plan unless the last tool result contradicts prior assumptions
  - If you cannot progress after 3 steps, ask one focused question

  # This prevents excessive internal reasoning loops

What You CANNOT Control:

Automatic Routing: The LLM decides which specialist to call based on descriptions --> for more deterministic behavior, consider agentic workflows
Parallel Processing: Currently, agent calls are sequential (one at a time)
Routing Algorithm: watsonx Orchestrate's internal orchestration logic
Response Time: Inherent to the LLM and tool execution time

Best Practices:

Keep hierarchies flat - Minimize agent layers
Write clear descriptions - Help the LLM route correctly
Use explicit instructions - Guide routing decisions
Limit tools per agent - Keep specialists focused (≤10 tools)
Design independent specialists - Avoid dependencies between agents
Test routing behavior - Verify the LLM routes as expected

6. Testing Strategies¶

Testing multi-agent systems involves three levels: testing individual specialists, testing routing logic, and testing complete workflows.

Understanding assert in Python Testing

Before diving into the examples, let's understand the assert statement used throughout:

# assert checks if a condition is True
# If True: test passes, continues
# If False: test fails, stops with an error

assert 5 > 3                    # ✅ Passes (5 is greater than 3)
assert "hello" in "hello world" # ✅ Passes ("hello" is in the string)
assert 2 + 2 == 4               # ✅ Passes (2+2 equals 4)

assert 5 < 3                    # ❌ Fails! (5 is NOT less than 3)
assert "cat" in "dog"           # ❌ Fails! ("cat" is NOT in "dog")

# In our tests, we use assert to verify agent behavior:
response = agent.chat("Find flights to Paris")
assert "flight" in response.lower()  # ✅ Pass if response mentions flights
                                     # ❌ Fail if response doesn't mention flights

Why use assert?

Automatically checks if your agent works correctly
Fails immediately when something is wrong
Makes it easy to run hundreds of tests automatically
Helps catch bugs before users see them

Now let's see how we use assert to test our multi-agent system:

Level 1: Unit Testing Individual Specialists

Purpose: Verify that each specialist agent works correctly in isolation, independent of the orchestrator.

# Test that the flight specialist can handle flight queries correctly
# This tests ONLY the specialist, not the routing to it

import pytest
from ibm_watsonx_orchestrate import Agent

def test_flight_specialist_search():
    """
    Test that flight_specialist correctly uses search_flights tool
    and returns flight information
    """
    # Load the specialist agent
    agent = Agent.from_yaml("flight-specialist-agent.yaml")

    # Send a query directly to the specialist
    response = agent.chat("Find flights from NYC to LAX on Dec 15")

    # Verify the response contains flight information
    assert "flight" in response.lower() or "airline" in response.lower()
    assert "NYC" in response or "New York" in response
    assert "LAX" in response or "Los Angeles" in response

def test_flight_specialist_with_mock_tools():
    """
    Test specialist behavior with mock tools to avoid external API calls
    """
    # Create mock tool that returns predictable data
    def mock_search_flights(origin, destination, date):
        return {
            "flights": [
                {"airline": "United", "price": 350, "departure": "08:00"},
                {"airline": "Delta", "price": 375, "departure": "10:30"}
            ]
        }

    # Load agent and replace tool with mock
    agent = Agent.from_yaml("flight-specialist-agent.yaml")
    agent.tools["search_flights"] = mock_search_flights

    response = agent.chat("Find flights from NYC to LAX")

    # Verify agent used the tool and formatted results
    assert "United" in response
    assert "350" in response or "$350" in response

Why Unit Test Specialists?

Verify each specialist's tools work correctly
Test specialist's response formatting
Ensure specialist handles errors gracefully
Faster than testing through orchestrator
Easier to debug when issues occur

Level 2: Integration Testing Routing

Purpose: Verify that the orchestrator correctly routes requests to the appropriate specialists.

def test_orchestrator_routes_to_flight_specialist():
    """
    Test that orchestrator recognizes flight queries and routes to flight_specialist
    """
    # Load the orchestrator agent
    orchestrator = Agent.from_yaml("travel-concierge-agent.yaml")

    # Ask about flights
    response = orchestrator.chat("I need to book a flight to Paris")

    # Check that response contains flight information
    # (indicating flight_specialist was called)
    assert "flight" in response.lower()

    # You can also check orchestrator's internal logs if available
    # to verify which collaborator was called

def test_orchestrator_routes_to_hotel_specialist():
    """
    Test that orchestrator recognizes hotel queries
    """
    orchestrator = Agent.from_yaml("travel-concierge-agent.yaml")

    response = orchestrator.chat("Find me a hotel in Paris")

    # Verify hotel-related response
    assert "hotel" in response.lower() or "accommodation" in response.lower()

def test_orchestrator_handles_ambiguous_query():
    """
    Test that orchestrator asks clarifying questions for ambiguous requests
    """
    orchestrator = Agent.from_yaml("travel-concierge-agent.yaml")

    response = orchestrator.chat("I want to go to Paris")

    # Should ask what kind of help is needed
    assert "?" in response  # Contains a question
    assert any(word in response.lower() for word in ["flight", "hotel", "help"])

Why Integration Test Routing?

Verify orchestrator's descriptions and instructions work
Ensure LLM routes to correct specialists
Test edge cases and ambiguous queries
Validate multi-specialist workflows

Level 3: End-to-End Workflow Testing

Purpose: Test complete user journeys involving multiple specialists and conversation turns.

def test_complete_trip_planning_workflow():
    """
    Test a realistic multi-turn conversation that uses multiple specialists
    """
    orchestrator = Agent.from_yaml("travel-concierge-agent.yaml")

    # Turn 1: Initial request
    response1 = orchestrator.chat("I want to plan a trip to Tokyo in March")
    assert "tokyo" in response1.lower()

    # Turn 2: Flight request
    response2 = orchestrator.chat("I need flights from New York")
    assert "flight" in response2.lower()

    # Turn 3: Budget constraint
    response3 = orchestrator.chat("My budget is $3000 total")
    assert "budget" in response3.lower() or "3000" in response3

    # Turn 4: Hotel request
    response4 = orchestrator.chat("What hotels do you recommend?")
    assert "hotel" in response4.lower()

    # Verify conversation context is maintained
    # (orchestrator should remember Tokyo, March, $3000 budget)
    assert "tokyo" in response4.lower() or "march" in response4.lower()

def test_error_recovery_workflow():
    """
    Test that system handles errors gracefully in multi-agent workflow
    """
    orchestrator = Agent.from_yaml("travel-concierge-agent.yaml")

    # Request with invalid date
    response = orchestrator.chat("Find flights to Paris on February 30")

    # Should handle gracefully, not crash
    assert response is not None
    assert "error" not in response.lower() or "invalid" in response.lower()

Why End-to-End Test?

Verify complete user journeys work
Test context retention across turns
Ensure specialists work together correctly
Validate real-world usage patterns

Testing Best Practices:

Start with unit tests - Test specialists individually first
Use mock tools - Avoid external API calls in tests for speed and reliability
Test routing explicitly - Verify orchestrator routes to correct specialists
Test conversation context - Ensure information carries across turns
Test error scenarios - Invalid inputs, missing data, tool failures
Use realistic queries - Test with actual user language, not just technical terms
Automate tests - Run tests on every code change
Test incrementally - Add tests as you add specialists

Example Test Structure:

tests/
├── test_specialists/
│   ├── test_flight_specialist.py
│   ├── test_hotel_specialist.py
│   ├── test_activity_planner.py
│   └── test_budget_advisor.py
├── test_routing/
│   └── test_orchestrator_routing.py
└── test_workflows/
    └── test_trip_planning_workflows.py

Part 7: Advanced Patterns¶

Pattern 1: Sequential Workflow¶

instructions: |
  For trip planning:
  1. Get flights first (determines dates)
  2. Get hotels second (based on flight dates)
  3. Get activities third (based on location and dates)
  4. Get budget analysis last (based on all selections)

Pattern 2: Conditional Routing¶

instructions: |
  If user mentions budget constraints:
  - Route to budget_advisor FIRST
  - Get budget recommendations
  - Then route to other specialists with budget in mind

  If user has no budget constraints:
  - Route directly to relevant specialists
  - Offer budget analysis at the end

instructions: |
  For complex requests:
  1. Get initial options from specialist
  2. Present to user
  3. If user wants refinements:
     - Route back to same specialist with new criteria
     - Repeat until user satisfied
  4. Move to next specialist

Pattern 4: Fallback Chain¶

instructions: |
  If primary specialist cannot help:
  1. Try secondary specialist
  2. If still cannot help, try general knowledge
  3. If still cannot help, escalate or admit limitation

Exercises¶

Exercise 1: Add a New Specialist (Easy)¶

Add a "Car Rental Specialist" to the travel system.

Requirements:

Create car-rental-specialist-agent.yaml
Create car_rental_tools.py with search and book functions
Update travel_concierge to include new specialist
Test routing to car rental specialist

💡 Ask Bob:

Bob, create a car_rental_specialist agent with tools for searching
and booking rental cars, and update the travel_concierge to route
car rental queries appropriately.

Exercise 2: Implement Budget-First Workflow (Medium)¶

Modify the orchestrator to always check budget first for trip planning requests.

Requirements:

Update travel_concierge instructions
Route to budget_advisor before other specialists
Use budget constraints when routing to other specialists
Test with budget-constrained requests

Exercise 3: Create a Different Domain (Advanced)¶

Build a multi-agent system for a different domain (e.g., e-commerce, healthcare, education).

Requirements:

Design 3-4 specialist agents
Create orchestrator with routing logic
Implement mock tools
Test complete workflows

Example Domains:

E-commerce: Product Search, Inventory, Checkout, Support
Healthcare: Appointment, Prescription, Billing, Records
Education: Course Search, Enrollment, Assignments, Grading

Common Issues¶

Issue: Orchestrator Not Routing¶

Symptoms: Orchestrator tries to answer directly instead of routing

Solutions:

Make specialist descriptions more specific
Add explicit routing rules in orchestrator instructions
Ensure collaborators are properly listed
Check that specialist agents exist and are imported

Issue: Context Lost Between Agents¶

Symptoms: Specialist doesn't have information from previous conversation

Solutions:

Update orchestrator to pass context explicitly
Include relevant details when routing
Have orchestrator summarize previous interactions

Issue: Circular Routing¶

Symptoms: Agents keep routing back and forth

Solutions:

Add clear termination conditions
Limit routing depth
Have specialists indicate when they're done
Orchestrator should synthesize, not re-route

Summary¶

In this lesson, you learned:

✅ When and why to use multi-agent systems
✅ How to design focused specialist agents
✅ How to create orchestrator agents with routing logic
✅ How to manage context and handoffs
✅ Best practices for multi-agent architectures
✅ Common patterns and anti-patterns

Key Takeaways¶

Separation of Concerns - Each agent has a clear, focused purpose
Clear Routing - Orchestrator has explicit logic for routing decisions
Context Management - Information flows smoothly between agents
Graceful Degradation - System handles errors and edge cases well
Maintainability - Specialists can be updated independently

Next Steps¶

Implement the exercises to reinforce learning
Try building multi-agent systems for your own use cases
Explore advanced patterns like parallel processing
Consider how to monitor and optimize multi-agent systems

Want to learn more? This completes the advanced multi-agent orchestration module. You can now apply these patterns to build sophisticated agent systems for any domain! 🚀

For testing and deployment best practices, refer back to Part 8: Testing & Deployment.

🧠 Knowledge Check¶

Ready to test what you've learned in this part?

Take the Part 9 Quiz →

Part 9: Multi-Agent Orchestration & Workflows¶

Overview¶

What You'll Learn¶

What You'll Build¶

Why Multi-Agent Systems?¶

Single Agent vs Multi-Agent¶

When to Use Multi-Agent Systems¶

Part 1: Understanding Agent Hierarchies¶

Agent Roles¶

Routing Strategies¶

Part 2: Building Specialist Agents¶

Step 1: Create Flight Specialist¶

Step 2: Create Hotel Specialist¶

Step 3: Create Activity Planner¶

Step 4: Create Budget Advisor¶

Part 3: Creating the Orchestrator Agent¶

Step 1: Design Orchestrator Instructions¶

Part 4: Implementing Mock Tools¶

Create Flight Tools¶

Create Hotel Tools¶

Create Activity Tools¶

Create Budget Tools¶

Part 4.5: Naming Convention for Shared Environment¶

Naming Pattern¶

Example¶

Complete Naming Checklist¶

Why This Matters¶

Part 5: Testing Multi-Agent Workflows¶

Import All Agents and Tools¶

Test Simple Routing¶

Test Complex Workflows¶

Part 6: Best Practices¶

1. Agent Design¶

2. Routing Logic¶

3. Context Management¶

4. Error Handling¶

5. Optimizing Agent Performance¶

6. Testing Strategies¶

Part 7: Advanced Patterns¶

Pattern 1: Sequential Workflow¶

Pattern 2: Conditional Routing¶

Pattern 3: Iterative Refinement¶

Pattern 4: Fallback Chain¶

Exercises¶

Exercise 1: Add a New Specialist (Easy)¶

Exercise 2: Implement Budget-First Workflow (Medium)¶

Exercise 3: Create a Different Domain (Advanced)¶

Common Issues¶

Issue: Orchestrator Not Routing¶

Issue: Context Lost Between Agents¶

Issue: Circular Routing¶

Summary¶

Key Takeaways¶

Next Steps¶

🧠 Knowledge Check¶
